HKUNICO® | HTL-3840E
Electro-hydraulic symmetric clear-floor 2-Post Lift with telescope double stage pick up pads and automatic engagement of mechanical safety locks with single point release system.
Technical data:
- Lifting capacity: 4000kg
- Min. height: 110mm
- Max. lifting height: 1900mm
- Overall height: 3674mm
- Overall width: 3384mm
- Width between posts: 2760mm
- Short arm length: 685~1,100mm
- Long arm length: 845~1330mm
- Lifting/lowering time: 55 Sec./35 Sec
- Motor power: 2.2kW
- Power supply: 220V/50Hz/1Ph
- Net weight: 700Kg
Workshop requirements
- Minimum Ceiling height of 4260mm
- 150mm steel mesh reinforced concrete (25-30 MPA)
- Baseplate extension kit available for 100 – 125mm concrete footing (Optional)
Warranty and Certification
- 12 months carry-in warranty against manufacture defect, effective from the date on delivery
- On-site service available on request, labour and transport charge apply (Including warranty period)
- JKKP design approved
What’s Not Included? (We’ll help find the best, most reliable rate and send you the invoice. Please contact us for a quote).
- Delivery by land or sea freight (The customer is always responsible for unloading the product from the truck).
- Installation at your companies premises
- Customer to supply electrical supply & connection to the equipment
Customer Support (Contact us directly):
- 011-53300199 | 011-35380700 | 016-2109299 | 016-2139299 | 012-3783703
FAQ:
Q1: What is the minimum ceiling height requirement for installing the HKUNICO HTL3840E? A: The HKUNICO HTL3840E has an overall height of 3,674mm. To ensure safe installation and operation, a minimum ceiling height of 4,260mm is required in your workshop.
Q2: Does the HKUNICO HTL3840E 2-post lift come with a warranty in Malaysia? A: Yes, it comes with a 12-month carry-in warranty against manufacturing defects, backed by HK Automotive. On-site service, labor, and transport support are also available upon request.
Q3: What are the primary electrical power requirements for this car hoist? A: It is powered by a reliable 2.2kW motor. Customers can choose between 220V/50Hz/1Phase or 380V/50Hz/3Phase power supply options depending on their workshop's electrical setup.
Q4: Are you an authorized distributor? A: Yes, HK Automotive is the exclusive authorized distributor of HKUNICO automotive equipment in Malaysia.
