LAUNCH® X431 PAD VII LINK Professional Diagnostic Tools (Trade-In Offer)

RM 12,800.00

LAUNCH | X-431 PAD VII
Original set register In MALAYSIA with certificate

LAUNCH High-end Flagship Diagnostic Tool

X-431 PAD VII LINK is an unexpected high-end diagnostic tool from LAUNCH, comes with the ADAS calibration function, 39 service functions, TPMS service and multiple extended modules functions. New Smartlink C VCI powers technicians a new diagnostic level without the limitation of diagnostic functions, tools and vehicle types.

Features:
  • Full system vehicle coverage for U.S., Asian and European markets over 110 brands, which is continually update
  • Upgrade and expand the X-431 PAD VII LINK with more software and service via the new module 'MALL' as demanded
  • Real-time voltage display helps technicians to monitor the voltage condition of vehicle during the diagnosis
  • Topology mapping gives a visual checking on DTCs and all systems communication status
  • X-431 FIX diagnostic database providing detailed interactive wiring diagrams and illustrations enables technicians to complete every repairing job
  • Support automotive communication protocols CAN/CANFD/DoIP and automotive communication standards J2534/D-PDU/RP1210
  • Auto-detects the communications protocol of the vehicle and assists to check automotive OBDII port pin damaged or not
  • Intelligent diagnostic enables identify VIN automatically and access the system quickly
  • Guided function for VW and AUDI
  • Optional ADAS calibration function increases more revenue
  • Advanced coding and programming function
  • An extended solution to support TPMS service
  • 2.4GHz & 5GHz dual-band communication ensures quick and stable connection
  • Empower technician to diagnose light, medium & heavy-duty vehicles with Smarlink C
  • The basic functions include reading & clearing DTC, remote diagnosis, Bi-directional control, live data graph, wireless software update etc.
  • Build-in repair information and training video modules help to track and fix issues fast

Specification:

  • X-431 PAD VII

Operation System

Andorid 9.0

CPU

2.0GHz Octa-core

Display

13.3' touch screen 1920*1080

Memory

8GB

Storage

256GB

Camera

Rear 13MP, Front 8MP

WiFi

Dual Band 2.4 & 5GHz

Diagnostic Communication

WiFi

Working Temperature

0℃~50℃

Dimension

353*236*71 mm

  • Smartlink

Display

3.5' touch screen  320*480

Memory

256M

Storage

8GB

WiFi

Dual Band 2.4 & 5GHz

Diagnostic Communication

WiFi & BT & USB

Working Temperature

0℃~50℃

Dimension

204*110*45 mm


Shipping method:

  • By local courier service

Warranty & Software update:

  • 1-year carry-in warranty against manufacture defect for hardware.
